Beschrijving: EVERYGLOW® Photoluminescent Vinyl Film
1. Overview
EVERYGLOW® Flame retardant Photoluminescent Vinyl Film is a high-performance, self-adhesive safety material engineered to provide superior visibility in total darkness. Manufactured using EVERYGLOW® high-purity Strontium Aluminate pigments, this photoluminescent vinyl acts as a “light battery,” absorbing energy from any ambient light source and releasing it as a brilliant glow for over 10 uren.
Specifically designed for the safety signage industry, this photoluminescent film is the gold standard for creating emergency egress markings, fire safety signs, and directional indicators that remain functional even when electrical systems fail.
2. Key Features
- High-Intensity Afterglow: Exceeds DIN 67510 Class C and D standards, providing a powerful initial luminance and a long-lasting, visible decay for 8–12+ hours.
- Excellent Workability: Optimized for computer-aided plotting, silk-screen printing, and wide-format digital printing (solvent, eco-solvent, and UV inks).
- Superior Adhesion: Features a permanent, pressure-sensitive acrylic adhesive that bonds securely to smooth surfaces such as metal, glass, plastic, and painted walls.
- Safety & Sustainability: 100% niet giftig, niet-radioactief, and lead-free. Requires no electricity, batteries, or maintenance.
- Weather & UV Resistance: Highly durable construction that resists shrinking and maintains luminescent integrity over long-term indoor and protected outdoor use.
3. Technical Specifications
| Property | Typical Value |
|---|---|
| Material Base | Multi-layer PVC |
| Glow Color | Yellow-Green (Standard) / Aqua-Blue |
| Glow Duration | 8–12+ Hours |
| Film Thickness | 0.25mm – 0.45mm (excluding liner) |
| Adhesive Type | P.S.A (Permanent Acrylic Pressure-Sensitive) |
| Standard Roll Size | 1.22m x 50m (Custom sizes available) |
| Compliance | DIN 67510, ISO 15370, IMO A.752(18), PSPA Class B/C/D |
4. Primary Applications
- Emergency Signage: Producing “EXIT” signs, fire extinguisher markers, and evacuation maps.
- Egress Path Marking: Creating floor tapes, Markeringen van trappen, and wall-mounted guidance strips.
- Industrial Safety: Highlighting hazardous equipment, low-clearance areas, and valve handles.
- Transportation: Safety markings for subways, tunnels, railway cars, and marine vessels.
- Decoratief & Creative: Custom glow-in-the-dark stickers, decals, and promotional graphics for nighttime branding.
5. Usage & Processing Guidelines
- Printing: Ensure inks are compatible with PVC substrates. Allow printed graphics to dry completely (24–48 hours) before lamination or application.
- Cutting: Use a standard 45 or 60 blade with medium pressure. Due to the pigment density, blades may wear faster than with standard vinyl.
- Toepassing: Apply to clean, dry, and non-porous surfaces. For large-scale signage, a squeegee or application roller is recommended to ensure a bubble-free finish.
- Opslag: Store rolls vertically in a cool, dry place away from direct sunlight to prevent “edge-glow” activation and adhesive degradation.
6. Performance Ratings
EVERYGLOW offers multiple performance tiers to meet specific project budgets and safety requirements:
- Class B: Standard glow for short-range visibility and decorative use.
- Class C: Professional safety grade for standard building egress.
- Class D: Ultra-high intensity for marine, offshore, and critical industrial infrastructure.
Everyglow ® Eco-solvent photoluminescent vinyl film are research by ourselves , which is choose EVERYGLOW photoluminescent pigment combine with acrylic polyster paint thru coating process,final apply with eco-solvent ink printing layer on the film surface .so it have good performance printing by eco-solvent ink printer.
it available glow more than 24 hours after absorb the visible light for 5-30mins,
en dit stoot uit & Absorbeer lichtproces wordt herhaaldelijk,Geen stroomverzoek.
Producten Eigenschappen:
Vrij van radioactieve elementen , niet giftig, ongevaarlijk, Milieuvriendelijk materiaal.
Longer afterglow time and super higher luminance.
Excellent printing by eco-solvent ink,uv ink, silk-screen ink.
Good weather resistant for outdoor use.
| Naam van het product | ES-Class C | Eco-solvent printable photoluminescent vinyl film | |
| Materiaal | Pvc | Uiterlijk | Yellowish |
| Dikte | 0.3-0.35Mm | Gloed kleur | Geel-groen |
| Breedte | 1.24m max | Life time in door | 10jaar |
| lengte | 25m / 50m | Life time outdoor | 3-7years |
| Self-adhesive | ja | Afterglow luminance mcd/m2 | 140mcd/m2 at 10mins |
| Printing ink | eco-solvent ink,uv ink,silk-screen ink | 20mcd/m2 op 60 minuten | |
1) Opgewonden door lichtbron D65 1000Lx gedurende 10 minuten;Notitie: De norm van de test: DIN67510 deel 1
2)De nagloeitijd geeft de tijd aan waarin het pigment afneemt tot 0.32 mcd/m2
3) De fout over ± 10% is toegestaan in bovenstaande gegevens.
Pak:
1.22m x 25m/50m, 61cm x 25m/50m ,each rolls put in one carton.
Toepassing:
These pigment is mainly apply as Safety photoluminescent sign, reclame,label,evacuation plan, bewegwijzeringssysteem enz.
